FOR A VIDEO OF THIS MACHINE: https://youtu.be/watch?v=GEj0kdQw4_k

CATALOG SPECIFICATIONS:
MAXIMUM SWING: 20"
MAXIMUM TURNING DIAMETER: 19.5"
MAXIMUM DISTANCE BETWEEN CENTERS: 59"
X-AXIS TRAVEL: 11"
Z-AXIS TRAVEL: 47"
BAR CAPACITY: 3.25"
RAPID TRAVERSE (X & Z): 160 & 320 IPM
SPINDLE SPEEDS-INFINITE (THREE RANGES): 7 - 2200 RPM
MACHINE DIMENSIONS: 120" x 68" x 64" HIGH
MACHINE WEIGHT: 7000 LBS. APPROX.

EQUIPPED WITH:
FANUC 0i-TD CONTROL
10" 3 JAW CHUCK
6 POSITION TURRET
15 HP SPINDLE MOTOR
TAILSTOCK
STEADY REST
COOLANT TANK AND PUMP

ROBERTS MACHINERY SALES LTD.
930 E. DRAYTON, FERNDALE, MI 48220
TEL: (248)543-4466
