WITH DIFFERENTIALSTOCK NO. 7003
CATALOG SPECIFICATIONS:
MAXIMUM DIAMETER OF GEAR HOBBED (WITH WORK SUPPORT): 18"
MAXIMUM DIAMETER OF GEAR HOBBED (WITHOUT WORK SUPPORT): 24"
MAXIMUM DIAMETRAL PITCH: 3
FACE CAPACITY: 15"
MAXIMUM DIAMETER OF HOB: 6"
TABLE DIAMETER (T-SLOTTED): 18"
DIAMETER INDEX WORM GEAR: 18"
HOB SPEEDS: 40 - 240 RPM
FEED RANGE: .03 - .200"
POWER OF MAIN MOTOR: 7.5 HP
MACHINE APPROX. FLOOR SPACE: 67" x 142" x 88" HIGH
MACHINE APPROX. WEIGHT: 11,000 LBS.
EQUIPPED WITH:
DIFFERENTIAL
INFEED
TAILSTOCK WITH OVERARM SUPPORT (30" MAXIMUM HEIGHT)
(2) HOB ARBORS - 1-1/4" & 1-1/2"
COOLANT SYSTEM
MISC. CHANGE GEARS
MISC. SPLASH GUARDING
