BUILT APPROX. 1971STOCK NO. 7002
CATALOG SPECIFICATIONS:
MAXIMUM DIAMETER OF GEAR HOBBED (WITH WORK SUPPORT): 32"
MAXIMUM DIAMETER OF GEAR HOBBED (WITHOUT WORK SUPPORT): 48"
MAXIMUM DIAMETRAL PITCH: 2-1/2
FACE CAPACITY: 18"
MAXIMUM DIAMETER OF HOB: 8"
TABLE DIAMETER (T-SLOTTED): 32"
INDEX RANGE (INCLUDING PRIMES): 15 - 100
HOB SPEEDS: (12) 27 - 160 RPM
FEED RANGE: .03 - .200"
POWER OF MAIN MOTOR: 15 HP
MACHINE APPROX. FLOOR SPACE: 83" x 172" x 94" HIGH
MACHINE APPROX. WEIGHT: 20,200 LBS.
EQUIPPED WITH:
DIFFERENTIAL
TAILSTOCK
COOLANT SYSTEM
HOB ARBOR
HARDENED WAYS
MISC. CHANGE GEARS
