BUILT 2019VERY LOW HOURS
FOR A VIDEO OF THIS MACHINE: https://youtu.be/4K1tZ8-TMTI?is=KZPnZzDrKcTaMjtK
CATALOG SPECIFICATIONS:
MAXIMUM SWING: 16"
SWING OVER CROSS SLIDE: 8.6"
MAXIMUM DISTANCE BETWEEN CENTERS: 30"
MAXIMUM RAPID ON Z-AXIS: 400 IPM
CROSS SLIDE TRAVEL: 8.5"
SPINDLE THRU HOLE: 2.12"
SPINDLE NOSE: D1-6
SPINDLE SPEEDS-INFINITE: 150 - 2500 RPM
TAILSTOCK QUILL TRAVEL: 5.75"
QUILL TAPER HOLE: NO. 6 MT
MACHINE DIMENSIONS: 87" x 45" x 76" HIGH
MACHINE WEIGHT: 3000 LBS. APPROX.
EQUIPPED WITH:
PROTO TRAK RLX 2 AXIS CONTROL WITH 15.6" LCD WITH TOUCHSCREEN
ELECTRIC HANDWHEELS FOR MANUAL OPERATION
JOYSTICK FOR CONVENIENT JOG
INCH/METRIC SELECTABLE
8" 3 JAW CHUCK
DORIAN QUICK CHANGE TOOL POST
COOLANT SYSTEM
TAILSTOCK
7.5 HP SPINDLE MOTOR
STEADY REST
